Butterfly Valve : Features
- Slips-in between line flanges, Wafer / Sandwich type, lug style, compact design, light in weight, easy to install.
- Elastomer-seat provides bubble tight shut-off.
- Rigid body, sturdy construction, long trouble-free life.
- Ratchet lever mechanism permits locking of disc position determined by system requirement.
- Wetted parts only of PP/PVDF, HDPE/SS and elastomer compatible with fluid.
- Square section shaft provides positive engagement between shaft and disc, between shaft and lever ensuring positive shut -off with quarter turn operation.
- Suitable for f low in either direction, seals in both directions and can be installed in either vertical or horizontal lines.
- Also available with double flanged end connection.
Size Range :
80 mm NB to 300 mm NB.
Drilling :
As per all internationally accepted standards, such as BS, DIN, ASA, 150, etc.
Hydrostatic Test :
At 10 kg/sq.cm.g for Body and 6 kg/sq.cm.g for Seat.
